RELIABILITY: Built with multi-busbar cells and a corrosion-resistant aluminum frame to exceed industry standards for durability in harsh marine and off-grid environments.

Key Features

• ✔ Bifacial Yield: Up to 20% more power vs standard panels.
• ✔ High Efficiency: Multi-busbar monocrystalline cells.
• ✔ Weatherproof: IP67 rated with sealed frame.
• ✔ Plug & Play: 60cm cables with MC4 connectors.

Technical Specs

Peak Power (Pmax)	100W
Max Power Voltage (Vmp)	17.31V
Max Power Current (Imp)	5.78A
Open Circuit Voltage (Voc)	20.92V
Short Circuit Current (Isc)	6.15A
Dimensions	770 x 670 x 30 mm
Weight	5.5 kg

System / Application	Model Compatibility	Notes
12V Battery Systems	AGM, Gel, Lithium, Lead Acid	Requires PWM or MPPT Controller
Marine / Boats	Yachts, Narrowboats, Barges	Excellent for reflective water surfaces
Vehicles	Campervans, Caravans, RVs	Standard rigid mounting compatibility

This panel is designed for fixed mounting using standard Z-brackets or corner mounts. It is pre-wired with 2 x 60cm of 4mm² solar cable. Connect directly to a solar charge controller (recommended 10A+) before connecting to your 12V battery bank. For maximum bifacial efficiency, mount at an angle above a reflective surface (e.g., white roof or light-coloured ground).

Is this a genuine Solarika part?

Yes, this is a premium Solarika solar panel, manufactured to professional grade standards for high-output off-grid performance.

How do I know if it is compatible?

Check the dimensions (770x670mm) and ensure your system is 12V. This SKU SWB-100M is compatible with all standard MC4 connectors and solar charge controllers.

What are the benefits of Bifacial technology?

Bifacial panels feature active solar cells on both the front and back. When light reflects off the mounting surface (albedo effect), the rear of the panel converts that extra light into electricity, providing more power per square metre than traditional panels.
