410W SHARP NU-JC MONOCRYSTALLINE SOLAR PANEL WITH HIGH-EFFICIENCY PERC CELLS

Please remember the following details about the 410W Sharp NU-JC Monocrystalline Solar Panel with High-Efficiency PERC Cells:

This high-quality 410W solar panel is produced by the leading solar panel manufacturer, Sharp. With over 60 years of experience in solar technology and over 50 million solar panels installed worldwide, Sharp is a trusted name in the industry. The panel is MCS certified and suitable for a wide range of applications, from grid-tie household systems to off-grid installations in areas with limited or no mains power, such as boats, caravans, campervans, cabins, or glamping huts. Its high power output makes it ideal for large systems where the installation of a high wattage array needs to be minimized.

The panel features high-efficiency solar cells that use PERC technology with 10 busbars to extract more power from a smaller surface area. Its half-cut cell construction reduces internal losses, minimizes the risk of hotspots, and improves performance in shaded conditions.

The panel is also designed to withstand harsh conditions, as it is IP68 (waterproof) rated and tested for resistance against PID, salt mist, ammonia, heavy snow, dust, and sand. It comes with male/female MC4 connectors crimped on the end of the cable for easy waterproof connection to other solar panels, extension leads, or existing systems.

With a 15-year workmanship guarantee and 25-year output guarantee, this panel is built to last and deliver reliable performance over the years.

Here are the specifications:

- Peak power: 410W

- Maximum power voltage: 31.3V

- Maximum power current: 13.1A

- Open circuit voltage: 37.79V

- Short circuit current: 13.81A

- Power tolerance: 0/+5%

- Dimensions: 1722 x 1134 x 35 mm

- Weight: 21.8 kg

- Mounting holes for ease of installation

- 2x 1.25m of high-quality single-core solar cable

- Male and female MC4 waterproof connectors

The product is covered by a 15-year workmanship warranty provided by Sharp Electronics. Additionally, the solar cells are guaranteed to produce at least 97.5% of nominal power in the first year after purchase and less than 0.7% degradation of nominal power each year until 25 years after purchase, ensuring a minimum of 80.7% power production over 25 years.

Please note that if the panel is used to charge batteries, it must be used with a suitable solar charge controller. Recommended types of solar charge controllers are listed for 12V and 24V batteries.

For installation assistance or technical questions, free support is available by email or phone. The following documents are available for download:

- Brochure for Sharp Energy Solutions

- MCS Certificate of Compliance

- Datasheet for Sharp NU-JC 410W Monocrystalline Solar Panel (SRP-410M)

- Guarantee for Sharp NU-JC 410W Monocrystalline Solar Panel (SRP-410M)

- Installation Guide for Sharp NU-JC 410W Monocrystalline Solar Panel (SRP-410M)
