SolaX X3 G4-V2 Hybrid 3 Phase Inverter HV 10.0kW

SolaX X3 G4-V2 Hybrid 3 Phase Inverter HV 10.0kW

#1: X3-HYBRID-G4-10.0-V2

SolaX X3 Hybrid Data Sheet

SolaX X3 Hybrid Manual

SolaX X3 Hybrid Warranty

SolaX X3 Hybrid G100 Certificate

High-efficient

• 150% PV oversized and 110% overload output Maximum 150% overload output
• Higher efficiency on charging and discharging, up to 97.5%
• Built-in shadow tracking function

Economic

• Maximum 16A DC input current, support for high power solar panel
• Store the surplus energy from PV to battery Low start output voltage makes inverter longer working time
• Less energy loss on battery to inverter

Intelligent

• Switchover time <10ms
• Quick configuration with U-disk
• Lithium & Lead-acid battery compatible
• CT compatible, loads respond within 0.3s
• Intelligent loads management(e.g., Heat pump)
• On & Off-grid parallel function, up to 150kW
• 5 work modes, 2 charging periods available
• VPP ready, ancillary service in power market
• Three-phase unbalanced output 50% nominal output power on single phase at most

Wi-Fi is now included with Solax X3-Hybrid-G4 V2 product so no need to purchase additional Wi-Fi equipment

PLEASE NOTE: We are still awaiting some documents from SolaX for this range - these will be uploaded as soon as they are received.

Weight: 34 kg
Rated Power: 10,000 W
Min PPT Voltage: 180 V
Max PPT Voltage: 950 V
DC Startup Voltage: 200 V
DC Shutdown Voltage: 0 V
Max Input Voltage: 950 V
Max DC Power: 10,000 W
Max AC Power (5 Minutes): 10,001 W
Surge AC Power (1 Second): 10,002 W
Max DC Current: 24 A
Max DC Inputs: 2
Has DC Fuses: 0
Connector: SUNCLIX
Included Connectors: 0
Euro Efficiency: 97 %
Transformer: HF
