Product Details
A highly reliable 3« digit autoranging digital multimeter with data hold function. Ideal for general maintenance work.
Wide range of functions with 29 ranges including:
- Continuity buzzer
- Transistor test
- Capacitance test
- Diode test
Supplied complete with test leads, holster, battery and manual.
Size: 172x83x38mm
Weight: 310g approx.
RoHS compliant
| Basic Functions |
Range
|
Best Accuracy
|
| DC Voltage | 200mV/2V/20V/200V/1000V | ñ(0.5%+1) |
| AC Voltage | 2V/20V/200V/750V | ñ(0.8%+3) |
| DC Current | 20æA/200æA/2mA/20mA/200mA/10A | ñ(0.8%+1) |
| AC Current | 200æA/20mA/200mA/10A | ñ(1%+3) |
| Resistance | 200?/2k?/20K?/200K?/2M?/200M? | ñ(0.8%+1) |
| Capacitance | 2æF | ñ(4%+3) |
| Special Functions | ||
| Diode test | Yes | |
| Continuity Buzzer | Yes | |
| Transistor test | Yes | |
| Sleep Mode | Yes | |
| Low Battery Display | Yes | |
|
Input Impedance for DC Voltage Measurement |
10M? | |
| Max. Display | 1999 | |
| Display size: | 61x32mm | |
| Power | 9V Battery (PP3) |
