Product Details
Enphase IQ7a 60/72 cell MC4 inegrated Microinverter 230VAC
#1: EN-IQ7A-72-M-INT Inverters - Micro Inverter Units
Enphase IQ7a Data Sheet
Enphase IQ7a Manual
Enphase IQ7a G99 Certificate
*Collections are not permitted due to health & safety regulations*
- Rating: 349W
- Phases: 1
This new IQ7A micro inverter can work with 60 and 72 cell solar panels up to peak power of 366VA
Product Features:
- Most Powerful Enphase Microinverter on the market with high power output of 366VA
- The IQ7+ has a power rating of 295VA making the IQ7A the better choice
- Lower clipping losses resulting in higher net energy availability
- The higher the PV module rate, the wider the difference between IQ7+ and IQ7A making the IQ7A the ultimate microinverter
- It is noteworthy that clipping losses with IQ7A is almost zero until 500Wp
- Easy to install and light weight
- Built-in rapid shutdown
- Optimized for high powered 60 and 72 cell modules
- Class 11 double insulated IP67 enclosure
- Smart Grid ready
Weight: 1.08 kg
Rated Power: 349 W
Min PPT Voltage: 18 V
Max PPT Voltage: 58 V
DC Startup Voltage: 33 V
DC Shutdown Voltage: 18 V
Max Input Voltage: 58 V
Max DC Power: 460 W
Max AC Power (5 Minutes): 366 W
Surge AC Power (1 Second): 366 W
Max DC Current: 14.5 A
Max DC Inputs: 1
Has DC Fuses: 0
Connector: MC4
Included Connectors: 0
Euro Efficiency: 96.5 %
Transformer: HF
MPPT Quantity : 1
Has Integrated DC Switch: No
Warranty: 25 years
