SolaX X3 G4-V2 Hybrid 3 Phase Inverter HV 10.0kW

#1: X3-HYBRID-G4-10.0-V2

SolaX X3 Hybrid Data Sheet

SolaX X3 Hybrid Manual

SolaX X3 Hybrid Warranty

SolaX X3 Hybrid G100 Certificate

High-efficient

150% PV oversized and 110% overload output Maximum 150% overload output
Higher efficiency on charging and discharging, up to 97.5%
Built-in shadow tracking function

Economic

Maximum 16A DC input current, support for high power solar panel
Store the surplus energy from PV to battery Low start output voltage makes inverter longer working time
Less energy loss on battery to inverter

Intelligent

Switchover time <10ms
Quick configuration with U-disk
Lithium & Lead-acid battery compatible
CT compatible, loads respond within 0.3s
Intelligent loads management(e.g., Heat pump)
On & Off-grid parallel function, up to 150kW
5 work modes, 2 charging periods available
VPP ready, ancillary service in power market
Three-phase unbalanced output 50% nominal output power on single phase at most

Wi-Fi is now included with Solax X3-Hybrid-G4 V2 product so no need to purchase additional Wi-Fi equipment

PLEASE NOTE: We are still awaiting some documents from SolaX for this range - these will be uploaded as soon as they are received.

Weight: 34 kg
Rated Power: 10,000 W
Min PPT Voltage: 180 V
Max PPT Voltage: 950 V
DC Startup Voltage: 200 V
DC Shutdown Voltage: 0 V
Max Input Voltage: 950 V
Max DC Power: 10,000 W
Max AC Power (5 Minutes): 10,001 W
Surge AC Power (1 Second): 10,002 W
Max DC Current: 24 A
Max DC Inputs: 2
Has DC Fuses: 0
Connector: SUNCLIX
Included Connectors: 0
Euro Efficiency: 97 %
Transformer: HF
